830824-B21 HPE P408i-p SR SAS-12G PCIe Controller Gen10

Unleash peak performance and advanced security for your 830824-B21 HPE ProLiant Gen10 servers with the HPE Smart Array P408i-p SR Gen10 controller. This enterprise-grade RAID card delivers.

HPE 830824-B21 OVERVIEW:

The 830824-B21 HPE Smart Array P408i-p SR Gen10 controller is an enterprise-class RAID controller that greatly increases performance in database, or server applications and delivers 12Gb/sec SAS connectivity on Gen10 HPE ProLiant servers when connected to 12Gb/s internal hard drives. The 830824-B21 operates in Mixed Mode which combines RAID and Host Bus adapter operations simultaneously. The HPE Smart Array P408i-p has eight internal SAS lanes, allowing connection to SAS/SATA hard drives and provides enterprise-class storage performance, reliability, security and efficiency.

The HPE 830824-B21 Smart Array P408i-p SR Gen10 Controller, supporting 12Gb/s SAS and PCIe 3.0, operates in Mixed Mode which combines RAID and HBA operations simultaneously. This controller offers enhanced security by encrypting data-at-rest on any drive with HPE Smart Array SR Secure Encryption.

HPE 830824-B21 SPECIFICATIONS:

• Main Part Number: 830824-B21
• Spare Part Number: 836269-001
• Assembly Part Number: 830826-001
• Manufacturer: HPE
• Device Type: Smart Array P408i-p SR Gen10
• Host Interface: PCIe 3.0 X8
• Internal Ports: 8 SAS/SATA lanes across 2 x4 internal Mini-SAS ports
• Controller Interface: 12Gb/s SAS/SATA 6Gb/s
• RAID Levels: 0, 1, 5, 6, 10, 50, 60, 1ADM (Advanced Data Mirroring), 10ADM
• Mixed Mode Support: Yes (RAID logic drives and Host Bus Adapter hard drives simultaneously)
• Physical Drive Support: Up to 238 Physical Drives
• Logical Drive Support: Up to 64 Logical Drives

HPE 830824-B21 COMPATIBILITY:

The 830824-B21 is compatible with the following Gen10 HPE ProLiant Servers:

• HPE ProLiant DL360 Gen10
• HPE ProLiant DL380 Gen10
• HPE ProLiant DL385 Gen10
• HPE ProLiant DL560 Gen10
• HPE ProLiant DL580 Gen10
• HPE ProLiant ML110 Gen10
• HPE ProLiant ML350 Gen10
• HPE ProLiant XL170r Gen10
• HPE ProLiant XL170r Gen10
• HPE ProLiant XL190r Gen10
• HPE ProLiant XL230K Gen10
